Auto Reset Bi-metal Control
Auto Reset Bi-metal Control
Technology: Safety limits and Controls
Product Category: Bi-metal
Application: HVAC
Brand: Therm-O-Disc
The 64T is a 3/4 inch bi-metal double pole single throw control that breaks two separate circuits simultaneously. The snap-action of the bi-metal disc provides high-speed contact separation resulting in excellent life cycle characteristics at electrical loads up to 25 amps at 240 VAC. It is used in both electric heat and appliance applications where double pole single throw switching is desirable.
- Function:
- Max Calibration:
- Max Electrical Amperage:
- Double Pole Auto Reset
- 177°C / 350°F
- 25
- Enclosed or exposed disc
- Variety of terminal configurations
- Surface and airstream mounting configurations
Auto Reset Bi-metal Controls
Auto Reset Bi-metal Controls
Technology: Safety limits and Controls
Product Category: Bi-metal
Application: Appliance, HVAC
Brand: Therm-O-Disc
The 44T series line of bi-metal temperature switches provide high contact speed separation resulting in exceptional life characteristics.
- Function:
- Max Calibration:
- Max Electrical Amperage:
- Moisture Resistant Auto Reset or One-Shot Fuse
- 149°C / 300 °F
- 1
- Low internal resistance
- Vibration resistant construction provides high reliability
- Available in one-shot fuse type (44F)
- UL Agency Recognition
Auto Reset Bi-metal Control
Auto Reset Bi-metal Control
Technology: Safety limits and Controls
Product Category: Bi-metal
Application: Appliance, HVAC
Brand: Therm-O-Disc
The 60T auto reset control from Therm–O–Disc® offers proven reliability in a compact, versatile, cost-effective design. The snap-action of the bi-metal disc provides high-speed contact separation resulting in excellent life cycle characteristics at electrical loads up to 25 amps at 240 VAC. The 60T carries global agency recognition and is used in many major appliances and HVAC applications.
- Function:
- Max Calibration:
- Max Electrical Amperage:
- Auto Reset
- 177°C / 350°F
- 25
- Single pole, single throw or single pole, double throw
- Enclosed or exposed disc
- Variety of terminal configurations
- Surface and airstream mounting configurations
Manual Reset Bi-metal Control
Manual Reset Bi-metal Control
Technology: Safety limits and Controls
Product Category: Bi-metal
Application: Appliance, HVAC
Brand: Therm-O-Disc
The 60T manual reset control from Therm–O–Disc® offers proven reliability in a compact, versatile, cost-effective design. The snap-action of the bi-metal disc provides high-speed contact separation resulting in excellent life cycle characteristics at electrical loads up to 25 amps at 240 VAC. The 60T carries global agency recognition and is used in many major appliances and HVAC applications.
- Function:
- Max Calibration:
- Max Electrical Amperage:
- Manual Reset
- 177°C / 350°F
- 25
- Agency approved “M2” trip free manual reset
- Enclosed or exposed disc
- Variety of terminal configurations
- Surface and airstream mounting configurations
Auto Reset Bi-metal Control
Auto Reset Bi-metal Control
Technology: Safety limits and Controls
Product Category: Bi-metal
Application: Appliance, HVAC
Brand: Therm-O-Disc
The 36T auto reset control from Therm–O–Disc® offers proven reliability in a compact, versatile, cost-effective design. The snap-action of the bimetal disc provides high-speed contact separation resulting in excellent life cycle characteristics at electrical loads up to 15 amps at 120VAC, and 10 amps at 250VAC.
- Function:
- Max Calibration:
- Max Electrical Amperage:
- Auto Reset
- 220°C / 428 °F
- 15
- Global agency recognition
- CTI 250 construction available
- Enclosed or exposed disc
- Plastic or ceramic construction
- Conical or gold contacts available
Moisture Resistant Bi-metal Control
Moisture Resistant Bi-metal Control
Technology: Safety limits and Controls
Product Category: Bi-metal
Application: Appliance, HVAC
Brand: Therm-O-Disc
The 37T auto reset bimetal control from Therm–O–Disc® offers proven reliability in a moisture resistant design. The bi-metal disc’s snap-action provides high-speed contact separation resulting in excellent life cycle characteristics at electrical loads up to 10 amps. The 37T carries global agency recognition and is used in a wide range of applications including residential and commercial refrigeration, heat pumps, and air conditioning.
- Function:
- Max Calibration:
- Max Electrical Amperage:
- Moisture Resistant Auto Reset
- 105°C / 221°F
- 10
- CTI 250 construction available
- Single pole, single throw or single pole, double throw
- Surface mount and multiple tube mounting configurations
- Wide variety of lead wire options available
- ATEX and IECEx standard 60079-15 to Zone 2 certified
Moisture Resistant Bi-metal Control
Moisture Resistant Bi-metal Control
Technology: Safety limits and Controls
Product Category: Bi-metal
Application: Appliance, HVAC
Brand: Therm-O-Disc
The 14T auto reset control from Therm–O–Disc® offers proven reliability in a moisture resistant design. The snap–action of the bi-metal disc provides high–speed contact separation resulting in excellent life cycle characteristics at electrical loads up to 25 amps. The 14T is used in applications including commercial refrigeration, heating and air conditioning.
- Function:
- Max Calibration:
- Max Electrical Amperage:
- Moisture Resistant Auto Reset or One-Shot Fuse
- 105°C / 221°F
- 25
- Contacts open or close on temperature rise
- Single pole, single throw or single pole, double throw
- Surface mount and multiple tube mounting configurations
- Wide variety of lead wire options available
HLX Manual Reset Bi-metal Limit
HLX Manual Reset Bi-metal Limit
Technology: Safety limits and Controls
Product Category: Bi-metal
Application: Appliance, HVAC
Brand: Therm-O-Disc
The HLX series manual reset limit control from Therm–O–Disc® offers a robust manual reset package that is capable of handling electrical loads up to 50 amps at 480VAC. The HLX series is commonly used in electric heating or specialty applications that require its high current and voltage handling capability.
- Function:
- Max Calibration:
- Max Electrical Amperage:
- Double Pole Auto Reset
- 149°C / 300 °F
- 50
- Double pole, single throw switching
- Exposed disc only
- M1 trip free construction
- Contacts open on temperature rise
- 10–32 screw terminals provided
Single Operation Bi-metal Control
Single Operation Bi-metal Control
Technology: Safety limits and Controls
Product Category: Bi-metal
Application: Appliance, HVAC
Brand: Therm-O-Disc
The 60F one-shot control from Therm–O–Disc® offers proven reliability in a compact, versatile, cost-effective design. The snap-action of the bi-metal disc provides high-speed contact separation resulting in excellent life cycle characteristics at electrical loads up to 25 amps at 240 VAC. The 60F carries global agency recognition and is used in many major appliances and HVAC applications.
- Function:
- Max Calibration:
- Max Electrical Amperage:
- One-Shot Fuse
- 177°C / 350°F
- 25
- One-shot fuse type operation
- Enclosed or exposed disc
- Variety of terminal configurations
- Surface and airstream mounting configurations
Single Operation Bi-metal Control
Single Operation Bi-metal Control
Technology: Safety limits and Controls
Product Category: Bi-metal
Application: Appliance, HVAC
Brand: Therm-O-Disc
The 36F fuse thermostat is a single operation version of the 36T. Once the electrical contacts have opened, they will not reclose unless the ambient temperature drops below +32°F (0°C), or below -31°F (-35°C).
- Function:
- Max Calibration:
- Max Electrical Amperage:
- One-Shot Fuse
- 220°C / 428 °F
- 15
- One-shot fuse type operation
- Enclosed or exposed disc
- Wide variety of terminals
